Categories of Zinc Wire цинкова тел
Pure zinc wire, zinc wire for thermal spray metalizing, zinc wire price, Zinc wire 0.25mm dia, Zinc wire 0.01in dia, Zinc wire 99.99%, Zinc wire reel, Zinc wire diameter 0.5mm, Zinc wires, Zinc Wire 99.9% Pure, Zinc wire 99.9999%, and Zinc Wire Zn Wire are common metal products, typically used in electrical equipment, mechanical systems, and building structures. Based on their applications and characteristics, these zinc-based wires can be categorized into several types.

1. Classification by Use
Depending on their purpose, zinc wires can be divided into:

Electrical zinc wires: Primarily used in electrical equipment and wiring due to their excellent conductivity and corrosion resistance (e.g., Zinc Wire 99.9% Pure).

Mechanical zinc wires: Employed in transmission and support components of machinery, offering high strength and toughness (e.g., Zinc Wire Zn Wire).

Building zinc wires: Used for reinforcement and structural support in construction, valued for corrosion resistance and plasticity (e.g., Zinc wire diameter 0.5mm).

2. Classification by Material and Manufacturing Process
Hot-dip galvanized wire: Made by coating steel wire with zinc via hot-dip galvanizing, providing corrosion resistance and a glossy finish.

Cold-drawn zinc wire: Produced by drawing zinc rods into fine wires (e.g., Zinc wire 0.25mm dia), offering high strength and smooth surfaces.

Electro-galvanized wire: Steel wire electroplated with zinc (e.g., Zinc wire 99.99%), combining corrosion resistance with aesthetic appeal.

3. Classification by Specifications and Sizes
Fine zinc wires: Diameters below 0.1mm (e.g., Zinc wire 0.01in dia), used in electronics and medical devices.

Thick zinc wires: Diameters of 0.1mm–3mm (e.g., Zinc wire reel products), common in electrical and mechanical manufacturing.

Large zinc wires: Diameters exceeding 3mm, ideal for structural reinforcement in construction.

Conclusion
Zinc wires are categorized by use, material, and specifications, with each type-such as zinc wire for thermal spray metalizing or Zinc wire 99.9999%-serving distinct industrial and everyday applications. Their versatility ensures widespread utility across sectors.



Chemical composition:

ITEM	Zn % ≥	Impurity %≤
		Pb	Fe	Cd	Cu	Sn	Al	TTL
BMPTZS	99.995	0.004	0.003	0.002	0.001	0.001	0.001	0.005
BMPTZS1	99.99	0.005	0.005	0.003	0.002	0.001	0.002	0.01

Mechanical characteristics:

ITEM	BMPTZS	BMPTZS1
SPECIFIC GRAVITY (g/cm3)	7.13±0.1	7.13±0.1
MELTING RANGE ºC	419.5ºC±1ºC	419.5ºC±1ºC
ELECTRICAL RESISTIVITY (mΩ.mm2 /m)20ºC	≤70	≤70
TENSILE STRENGTH (Rm N/mm2)	95-130	95-135
ELONGATION AFTER RUPTURE (A 100mm %)	≥30	≥20

Diameter: 0.6mm≤Ф≤4.80mm

Product packing:

Hard paper drum	150-250 kg	outer diameter 550 mm, inner diameter300mm, variable height
Hard paper drum	40-110 kg	outer diameter 400 mm, inner diameter190mm. variable height
Plastic spool	15 kg	flange300mm, width100mm, center hole:55mm
Plastic spool	20 kg	flange270mm, width103mm, center hole:55mm
Steel drum	380 kg	outer diameter 560 mm, inner diameter310mm, height 800mm
bundle	20-40 kg

Pallet will be used, such as 1100mmX1100mm, 1200mmX800mm, 1000mmX1000mm, 800mmX800mm.
